Hatch HR3800 38 Watt 4 Pin 120 Volt 1 Lite CFL Electronic Ballast
Hatch Transformers HR3800 - 38 WATT HR SERIES 1-LAMP COMPACT FLUORESCENT BALLAST
38W - 4 Pin - 120 Volt - 1 Lite - Hatch CFL Electronic Ballast
Hatch Transformer HR3800 HR Low Profile One Lamp 38W 4-pin CFL Hardwire Ballast
Compact Fluorescent Hardwire Ballast Features:
Auto Restart After Hot Relamp, Deactive Lamp Protection Circuit, Flicker Free Operation,
High Power Factor, Low THD, 100% Factory Tested, High Reliability, No Audible Noise,
True Preheat Starting, No Starting Aid Required, Energy Efficient, High Frequency Operation
Solid State, Moisture and Shock Resistant, No PCBs, Side Leads with Feet
Hatch Transformers HR3800 Environmental Specifications:
Maximum Case Temperature: 70˚C at “T” point
Minimum Starting Temperature: -25˚C
Sound Rating: A+
Operating Humidity: 95% relative humidity, non-condensating
Environmental Protection: Epoxy Sealed for moisture resistance and shock vibration resistance
Safety Listing: Class P Type 1 outdoor
Hatch Transformers HR3800 Equivalent or replaces:
Hatch Transformers HR3800 replaces
GE2D: F38/2D/4P
GE BIAX:
OSRAM:
PHILIPS:
Additional Info
Additional Information
Manufacturer | Hatch Transformers |
---|---|
MPN | HR3800 |
Collection | Electronic Ballast |
UPC | 797281423801 |
Energy Star Rated | No |
UL Rated | Type 1 Outdoor |
California Status | Compliant |
Type | Electronic |
Ballast Type | Compact Fluorescent |
Housing / Case Style | Low Profile |
Mounting | With Feet |
Leads | Leads Out Both Sides |
Output Power (Wattage / Equivalent) | 38 Watts |
Input Voltage | 120 VAC |
Amperage | 0.31 Amps |
Number of Lights | 1-Light |
Power Factor | 0.99 |
Finish | White |
Length (MOL) | 4.50 inches |
Width | 1.75 inches |
Height | 1.00 inches |
RoHS COMPLIANT (Mercury Free) | Yes |
Warranty | 5 Years |
Master / Inner Carton Quantity | 50 |
Bulb Base Type | 4-Pin |
Bulb Type | Compact Fluorescent (CFL) |
