Hatch Transformers HR1300-277 - 13 WATT HR SERIES 1-LAMP COMPACT FLUORESCENT BALLAST
13W - 4 Pin - 277 Volt - 1 Lite - Hatch CFL Electronic Ballast
Hatch Transformer HR Low Profile One Lamp 13W 4-pin CFL Hardwire Ballast
Compact Fluorescent Hardwire Ballast Features:
Auto Restart After Hot Relamp, Deactive Lamp Protection Circuit, Flicker Free Operation,
High Power Factor, Low THD, 100% Factory Tested, High Reliability, No Audible Noise,
True Preheat Starting, No Starting Aid Required, Energy Efficient, High Frequency Operation
Solid State, Moisture and Shock Resistant, No PCBs, Side Leads with Feet
Environmental Specifications:
Maximum Case Temperature: 70˚C at “T” point
Minimum Starting Temperature: -25˚C
Sound Rating: A+
Operating Humidity: 95% relative humidity, non-condensating
Environmental Protection: Epoxy Sealed for moisture resistance and shock vibration resistance
Safety Listing: Class P Type 1 outdoor
Equivalent or replaces:
Hatch Transformers HR1300-277 replaces
GE BIAX: F13DBX or F13TBX
OSRAM: CF13DD/E or DULUX D/E 13
PHILIPS: PL-C 13W/4P
Additional Info
Additional Information
| Manufacturer | Hatch Transformers |
|---|---|
| MPN | HR1300-277 |
| Collection | Electronic Ballast |
| UPC | 797281421142 |
| Energy Star Rated | No |
| UL Rated | Yes |
| Ballast Type | Compact Fluorescent |
| Amperage | 0.06 Amps |
| Finish | White |
| Length (MOL) | 4.50 inches |
| Width | 1.75 inches |
| Height | 1.00 inches |
| Bulb Base Type | 4-Pin |
| Bulb Type | Compact Fluorescent (CFL) |
